| project | Unit(kg) | CPC (D) 20 |
| Rated lifting capacity | mm | 2000 |
| Load center distance | mm | 500 |
| Lifting height | mm | 3000 |
| Maximum height during operation | mm | 4030 |
| Mast angle (front/rear) | mm | 6/12 |
| Minimum ground clearance | mm | 110 |
| Minimum turning radius | Km/h | 2170 |
| Maximum travel speed (forward/reverse) | Mm/s | 20/19.5 |
| Maximum lifting speed (full load/no load) | Mm/s | 500/530 |
| Maximum descending speed | % | ≤600 |
| Maximum climbing with full load | mm | 20 |
| Overall vehicle shape (length * width) | mm | 3590*1160 |
| Fork (length * width * height) | mm | 1070*122*40 |
| Body Without Fork Factory | mm | 2520 |
| Speed of mast without lifting | mm | 1995 |
| Roof guard height | mm | 2070 |
| Maximum adjustment distance of fork | mm | 245-1020 |
| Wheelbase | mm | 1600 |
| Wheel base (front wheel/rear wheel) | mm | 970/970 |
| Braking distance (no load) | - | 3800 |
| Tires (front wheel/rear wheel) | 7.00-12-12PR/6.00-9-10PR | |
| engine model | - | 490BPG |
| engine capacity | L | 2.5 |
| Engine rated power/speed | Kw/rpm | 37/2650 |
| Engine torque/speed | Nm/rpm | 148/2000 |
| Fuel tank capacity | L | 58 |
| Vehicle quality | kg | 3400 |
